Description
New for 2024 the DLA-NZ700 from JVC is the world's smallest native 4K projector. With 2300 lumens and 80,000:1 contrast ratio you can experience full scale high definition images in a compact design.
While maintaining a small footprint, the NZ700 projector incorporates JVC's proprietary Blu-Escent laser light source and native 4K devices. The exhaust has been installed at the rear to reduce the impact of heat on the projection screen and to enable greater flexibility in installation.
Signals input via the 32Gbps 4K/60p HDMI terminal go through the 3rd Gen 0.69" native 4K D-ILA device to project full native 4K resolution images (4,096 x 2,160 pixels). JVC's Blu-Escent laser light source and a native contrast ratio of 80,000:1 achieves images filled with reality.
This Blu-Escent Laser light source designed especially for the DLA-NZ700 is capable of achieving exceptional peak brightness of 2,300 lumens with longevity of 20,000 hours. Housed in compact casing, the laser light engine provides higher output, greater efficiency and quieter operation, making it an excellent solution for demanding home cinema installations.
The 1.6x fully motorised zoom and focus 80mm 4K lens is capable of projecting high resolution images to every corner of the screen, while securing wide shift ranges of 70% vertically and 28% horizontally for flexible installation.
The Gen2 Frame Adapt HDR function instantaneously analyses the different peak brightness per scene or per frame for HDR10 content and performs real time tone mapping for optimised brightness, colour and details.
When combined with the new Deep Black Tone Control, DML and Filmmaker Mode the projector detects and analyses data contained in HDR sources to project the best of what each source has to offer.
Specifications:
| Device | 3rd Generation 0.69" Native 4K D-ILA device (4,096 x 2,160) x 3 |
| Display Resolution | 4,096 x 2,160 |
| Lens | x 1.6 motorised zoom and focus |
| Lens Diameter | 80mm diameter |
| Lens Shift | Vertical: ±70% Horizontal: ±28% Motorised in 16:9 aspect ratio |
| Screen Size (Diagonal) | 60" to 200" |
| Light Source | BLU-Escent laser diode |
| Brightness | 2,300lm |
| Contrast Ratio | Native: 80,000:1 Dynamic: ∞:1 |
| Cinema Filter Colour Gamut | DCI 98%/BT.2020 73% |
| HDMI | 2 (32 Gbps/HDCP 2.3). No support for CEC |
| LAN | 1 x RJ45 |
| Service Terminal. Service | 1 USB Type A for firmware update and backing up settings |
| Power | Consumption: 280 W Network Standby: 1.5W Eco Mode Standby: 0.3W Requirement: AC 100 to 240V, 50/60Hz |
| Dimensions | Including Feet: Height: 181mm / 7.13" Width: 450mm / 17.72" Depth: 479mm / 18.86" |
| Weigh | 14.8kg / 32.63lb |
Features:
- Completely redesigned interior and exterior in world's smallest native 4K projector
- High brightness of 2,300 lumen provides vibrant and dynamic images
- Native Contrast Ratio of 80.000:1
- New Blu-Escent laser light source
- 3rd Generation 0.69" 4K D-ILA (4096 x 2160) device x 3
- New 80mm, 15 element and11 group high quality lens
- 2 x HDMI (32 Gbps, HDCP 2.3) inputs, supporting 4K60P input signals
- HDR10+ contains the metadata of the original for each scene and with such data, the projector is able to automatically reproduce images as the creator intended
- Gen2 Frame Adapt HDR dynamically tone maps any HDR10 content frame by frame or scene by scene and automatically performs adjustment to achieve optimal images
- Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever
- FILMMAKER MODE™ that faithfully recreates the creator's intentions
- ISF C3 (Certified Calibration Controls) mode to reproduce excellent picture quality optimised for specific environments
- Wide Colour Gamut above exceeds DCI/P3 spec creating saturated delivering beautiful images that come to life
- Comes in a black finish only
User guides
Download User Guides:
Data Sheet
2024 D-ILA Range
User Manual
Throw Distance Guide
