Description
Description:
The Ubiquiti UDM-SE UniFi Dream Machine Special Edition Enterprise Network Appliance is an enterprise grade UniFi OS console capable of helping home and business owners alike seamlessly scale and manage their networks with high speed and dual WAN connectivity 10G SFP+ and 2.5GbE RJ45, whilst also incorporating a Gigabit PoE switch and a network video recorder (NVR) with 128 GB of internal storage.
The UDM-SE includes the UniFi Network Controller for managing your UniFi switches and access points. It combines with a fully managed switch with 10 Gbps SFP+ downlink and 8 x RJ45 GbE ports for scaling up, with all 6 x Ports providing PoE ad 2 x Ports providing PoE+.
The router features UniFi Protect functionality for convenient monitoring and complete management of your camera surveillance system. Video recordings are stored on the built in NVR. The hard driveis not included and can be accessed using the UniFi Protect mobile app. Via remote access, you can securely view the recordings that are privately stored on the UDM rather than a third party server or service.
As a enterprise class Security Gateway the UDM-SE combines routing with 10 Gbps SFP+ WAN, application visibility, VPN services and 3.5 Gbps full threat management throughput into a single device.
With redundancy options of Dual WAN with failover and supporting dual internet ISP connections, if the primary WAN connection drops it will automatically switch to the second WAN connection. The UDM-SE supports Ubiquiti's PSU failover system, the If the internal power supply unit fails, the proprietary USP RPS interface acts to provide redundant power for backup.
UniFi provides a integrated network management system for all network elements with an easy to use and modern user interface. Radio AI automatically optimises the Wi-Fi network.
Features:
- 1.7 GHz quad core processor
- Dual WAN ports 10G SFP+ and 2.5GbE RJ45
- 8 x GbE RJ45 ports, including 6 x 802.3af PoE and 2 x 802.3at PoE+ LAN ports
- 1 x 10G SFP+ LAN port
- 1 x 1.3" LCM color touchscreen for at a glance network monitoring
- Customisable internet threat filtration and traffic identification for enhanced network security
- Quick, Bluetooth powered setup via the UniFi Network web application or mobile app
- 1U sized, rack mountable device
- Connect a SmartPower Redundant Power System to create an uninterruptible network
- Integrated security gateway and UniFi protect ready NVR that supports compatible 3.5" HDDs
- 128 GB integrated storage for full UniFi OS Application experience
Specifications:
| Processor | Quad core ARM® Cortex® A57 at 1.7GHz |
| System Memory | 4 GB DDR4 |
| On Board Storage | 16 GB eMMC |
| Management Interface | Ethernet Bluetooth |
| LCM Display | 1.7" Touchscreen |
| Network | |
| LAN 10/100/1000 RJ45 Ports | 8 x GbE RJ45 Ports with PoE |
| LAN Uplink Ports | 1 x 10 Gbps SFP + |
| LAN Ports | 1 x 1Gbps RJ45 |
| WAN Ports | 1 x 1 GbE RJ45 Port |
| WAN Uplink Ports | 1 x 10 Gbps SFP + |
| PoE Power | 95W |
| PoE+ Enabled Ports 802.3af | 6 |
| PoE+ Enabled Ports 802.3af/at | 2 |
| Max. PoE Wattage Per Port by PSE 802.3af | 15.4W |
| Max. PoE Wattage Per Port by PSE 802.3af/at | 30W |
| PoE+ Power and Voltage | PoE: 44 to 57V PoE+: 50 to 57V |
| Gateway Features | |
| IDS/IPS Throughput | 3.5 Gbps |
| Performance | Redundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain and country based QoS Application and device type identification Additional internet failover with LTE backup Internet quality and outage reporting |
| Next Generation Security | Application aware firewall rules Signature based IPS/IDS threat detection Content, country, domain and ad filtering VLAN/subnet based traffic segmentation Full stateful firewall |
| Advanced Networking | License free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site to site VPN One click Teleport and Identity VPN Policy based WAN and VPN routing DHCP relay Customisable DHCP server IGMP proxy IPv6 ISP support |
| Power Method | 1 x Universal AC input 100 to 240V AC, 50/60 Hz 1 x USP-RPS DC input |
| Power Supply | AC/DC, internal, 50W |
| Max Power Consumption | 33W |
| Operating Temperature | -10°C / 14°F to 40°C / 104°F Relative Humidity: 5% to 95% non condensing |
| Rack Size | 1U |
| Dimensions | Height: 43.7mm / 1.7" Width: 442.4mm / 17.4" Depth: 285.6mm / 11.2" |
| Weight | 3.9kg / 8.6lb |
| Mounting Options | Rack |
| Included | UK power supply 2 x Rackmount brackets 8 x Bracket screws 4 x Mounting screws 4 x Cage nuts 1 x Security screw 4 x 2.5" HDD screws 4 x Rubber feet |
User guides
Download User Guides:
Data Sheet
Unifi Brochure
Installation Guide
DoC
